PVC Fittings
PVC Male Adapter (MAD)
PVC-U male adapter — solvent-weld socket on one end, male BSP or NPT thread on the other — for connecting PVC pipe into female-threaded valves, hose bibs or pump ports. Hex flats for spanner tightening. DN20 – DN200, PN10 / PN16.
- Raw Materials
- PVC-U lead-free compound
- Diameter Range
- DN20 – DN200 mm
- Pressure Rating
- PN10 / PN16
- Standards
- ISO 1452-3 / EN 1452-3 / ASTM D2466 / D2467
- Joint Type
- Solvent-weld socket × male threaded BSP / NPT
- Color
- Light grey / dark grey / white (custom on request)
- Applications
- Water supply, irrigation, drainage, pool / spa, industrial pressure piping
Product Description
The Primepoly PVC male adapter (MAD) connects PVC-U pipe to a female-threaded valve, hose-bib or pump port. Solvent-weld socket on one end, male BSP or NPT thread on the other, with hex flats for spanner tightening — the inverse of the female adapter and equally common in pumped systems and instrumentation lines.
Advantages and Characteristics
1. Solvent-weld × male-thread design per ASTM D2466 with BSP / NPT options.
2. Hex flats moulded into the body for safe spanner tightening without crushing the socket.
3. Reinforced root section to resist cracking under thread torque.
4. PTFE-tape compatible thread; no metal-to-plastic dissimilar-material concerns.
5. DN20 – DN200, PN10 / PN16.
Typical Applications
Connecting PVC pipe to female-threaded ball valves, hose bibs, garden taps, pump suction / discharge ports, chemical-dosing pump heads, irrigation solenoid valves and threaded pressure-relief valves. Universal in pump rooms, irrigation control valve clusters, and pool / spa filter manifolds.
Quality and Compliance
Every Primepoly PVC male adapter is moulded from food-grade, lead-free PVC-U compound and tested to ASTM D2466 (Sch 40), ASTM D2467 (Sch 80), ISO 1452-3 and EN 1452-3. Optional NSF/ANSI 61 certification is available for potable-water service. Pressure ratings PN10 / PN16, working temperature 0–60 °C, service life over 50 years when installed per manufacturer guidelines.
